SF133A Water-Resistant Emergency Pull-Cord Station
The SF133A Water-Resistant Emergency Pull-Cord Station includes a call button, optional pullcord, an LED for call indication, and a reset button. When a call is placed, it is registered at the master station, room controller with dome light, zone lights, and duty station.
Button caps for call types include: CALL, EMERG, CODE, RESET, ROUND, and CHECK-IN. To create custom call types, you can utilize the LS450 ConfigTool software.

The SF133GK Gasket Kit must be installed with the SF133A to provide a proper seal to protect the unit in humid or wet locations.
Features
- Use push button or pull cord to place call
- Choose whether to install pull cord during installation
- Call assurance LED flashes when a call is placed
Specifications
Dimension: 4.58"H x 3.25"W x 1.03"D (116 mm x 83 mm x 26 mm) Environment: 5%-95% non-condensing humidity; 0 - 60 degrees Celsius Construction: PC board with quality electronic components mounted on a flame-retardant (UL 94V-0) plastic faceplate Mounting: Attach included back plate to a standard single-gang ring or sing-gang ring and box Connections: Lever-actuated connectors SKU SF133A Condition New Manufacturer Tektone Manufacturer_1 TekTone
