Rath - Avire SUB12ZONE 12 Zone Dist Module Sub

Rath SUB12ZONE - Area of Refuge System Expander for 12-Zone Site Upgrades

Rath - Avire SUB12ZONE 12 Zone Dist Module Sub is a key part of the distributed submodule and contains the logic for distributing signals and power throughout the Rath-Avire emergency communication system. The SUB12ZONE is a 12-zone, engineered submodule that connects to a Command Center cabinet to provide interconnection or "brain" function to distribute both signals and power from the master station to up to twelve individual remote stations.

What it Does

The SUB12ZONE provides a means to distribute incoming communications received at the Command Center to up to twelve individual remote locations (e.g., area of refuge boxes and elevator telephones) in a twelve-zone configuration. Each incoming call that is received by the SUB12ZONE will be assigned an appropriate zone so that two-way voice communications and power can be routed to and from each of the two corresponding locations across the emergency communication network.

Specification

• Model Number: SUB12ZONE
• Number of Addressable Zones: 12 addressable zones
• Product Class: Distribution Module - Sub Assembly
• Compatible Command Centers: Rath-Avire 2500 Series Command Centers
• Wire Configuration: One pair of wires required for each remote station to home-run configuration
• Mounting Method: Internal Mounting Option in Appropriate Enclosure
• Compliance Standards: All systems are compatible with standard commercial systems; provide full ADA, IBC and NFPA 72 compliant solutions.

Key Features and Benefits

• Expandable System Design: The 12 Zone System can be expanded and/or serviced very easily without having to buy new console parts.
• Simple Diagnostic/Service: There is easy access to each zone wiring at the main terminal block wiring diagram so the technician can quickly troubleshoot and find out why a zone is not working.
• Each station is designed to have its own dedicated pair of wires; therefore, if any one of the wires is damaged, all other stations and zones will remain in service.
• The products have been manufactured for life safety purposes; constructed to operate 24 hours a day for 7 days a week; and were designed with structural integrity and operational reliability in mind.
• Easy to use with existing Rat-avire distribution cabinets allowing for a neat and professional appearance at the point of installation.

Commonly Used Applications

The SUB12ZONE is utilized for communication systems in designated areas of Rescue Systems, where communications can be sent by call boxes located within stairwells/elevator lobbies. The SUB12ZONE is generally utilized in a variety of environments requiring these types of communication systems, including:

• K-12 facilities and small segments of universities/colleges that have intercom systems allowing security personnel to perform duties and assist users inside educational institutions
• Health care facilities that provide emergency assistance telephones providing patients with the ability to contact health care professionals from inside a clinic or nursing unit
• Multi-story Parking Structures utilizing Emergency Telephones providing the ability for Multi-story Parking Structures to have emergency telephones that are interconnected throughout the parking structure.
