Rauland Responder Wireless Bed Interface 301210

Description:

The Pullcord Anti-Ligature is ideal for applications where extra safety precautions are needed to minimize the risk of resident self-harm. The Pullcord is designed to break with a low breaking force without elongation yet provides a secure connection point to the pullcord station. Three ergonomically designed pull rings accommodate the placement of the resident's hand or other assistive devices at multiple intervals on the pull cord. The pullcord and pull ring contain an anti-microbial additive for infection control.

The Pullcord Anti-Ligature is compatible with all Responder pullcord stations. The Pullcord Anti-Ligature can be installed on existing pullcord stations without removing the station from the wall allowing easy conversion with minimal disruption in the patient room. The word "Rauland" is indelibly printed along the pullcord to distinguish it from standard Rauland pullcords.

Rauland 301210-REF Features:

• Anti-Ligature Design: The pullcord is designed to break at a safe force of 13 Ibf ± 3 Ibf (57.8 N ± 13.4 N), reducing the risk of injury and preventing ligature hazards.

• Ergonomic Pull Rings: Three pull rings are strategically placed at multiple intervals along the cord, allowing easy access and use by individuals with varying physical abilities.

• Antimicrobial Properties: The pullcord and pull rings are treated with an antimicrobial additive, helping to prevent bacterial growth and promote infection control.

• Flexible Configuration: Up to three pull rings can be positioned along the cord, providing flexibility in placement to accommodate patient needs and room configurations.

• Universal Compatibility: Fully compatible with all Responder pullcord stations, making it easy to integrate into existing systems without the need for modifications.

• Quick and Easy Replacement: The pullcord can be quickly replaced in the field without the need for specialized tools, minimizing downtime and simplifying maintenance.

Benefits:

• Anti-ligature cord breaks at 13 Ibf +/- 3 Ibf (57.8 N -r/-13.4 N)

• Pull ring designed to accommodate various disabilities

• Pullcord and pull rings contain an anti-microbial additive

• Up to three pull rings allow placement on cord at multiple intervals

• Compatible with all Responder pullcord stations

• Quick and easy field replacement for existing pullcords

Specifications:

• Cord Material: TPU Thermoplastic Polyurethane Elastomer Polyether Base with nylon core and anti-microbial additive

• Cord Length: 10 ft (3.04 m)

• Cord Breakage: 13 Ibf +/- 3 Ibf (57.8 N +/- 13.4 N)

• Pull ring Material: PC/ABS with anti-microbial additive

• Pull ring Dimensions: W: 3.43” (87.12 mm), H: 3.13” (79.48 mm), D: 0.40" (10.20 mm)

• Pull ring Quantity: 3

• Certification: CE, RoHS/WEEE

• The 350033 design satisfies the applicable advice and guidance of the Health Technical Memorandum HTM08-03: Bedhead Services. In addition, the cord is designed to break at lower force than the requirement specified in AS 3811 Hard-Wired Patient Alarm Systems.
