Rath - Avire P40+SLEDGE P40+Slimline Edges Only

Rath P40+SLEDGE - Safety Communications Edge Hardware for Door Sensors

In order to protect passengers using elevators, the Rath - Avire P40+SLEDGE P40+Slimline Edges Only is the best solution available today. The P40+SLEDGE is an infrared detection edge set that is used in conjunction with the Pana40+ Series of elevator control systems and has been specifically designed to be an ultra-thin edge detection system to accommodate new space constrained elevator doors.

The P40+SLEDGE consists of multiple infrared beams (created using a dense matrix of beams), which create a safety curtain that allows for realtime detection of objects in the doorways.

The P40+SLEDGE is designed specifically for traffic areas with a focus on safety. The slim profile of the edges makes it a great option for providing a flush installation in a new elevator and a great option to modernize an existing elevator.

How It Works

The P40+SLEDGE edge set is the primary sensor that provides 2D detection to the elevator door controller to prevent contact between passengers and the elevator doors.

Obstacle Detection is achieved by scanning the door opening with several infrared beams. If an object passes through one of the beams, the P40+SLEDGE provides an immediate signal to the elevator controller to reverse the direction of the doors.

Precision Monitoring: The P40+SLEDGE utilizes its ability to detect obstacles in front of it prior to physically touching them, significantly reducing the chance of injury and wear on the equipment compared with mechanical safety edges.

Ambient Light Filtering: Sensors are designed to ignore reflections from stainless steel doors and excessive ambient light to avoid creating “ghost” or delayed doors.

Technical Data

• Model Number: P40+SLEDGE (Slimline Edge Set)
• Profile Thickness: 15.5 mm (0.61”) for tight clearance doors
• Detection Height: 72”(Standard Coverage — Passengers)
• No. of Diodes: 40 High Output Infrared Diodes
• Beam Density: Up to 194 Overlapped Beams
• Response Time: Less than 50 milliseconds to open a door
• Ingress Protection: IP54 rated (Protection from dust and splash water)
• Operating Voltage: 5 VDC (Powered through P40+ Contoller)

Key Features and Benefits

• Small Size & "Slimline" Profile: The slimline design results in only a small amount of material used on the door which allows for tight-clearances thus enhancing the safety within the passenger zone.
• Passenger Safety: The 194 beam pattern will detect even small objects such as canes or straps.
• Durability & Reliability: The solid state design ensures that there are no mechanical points of failure giving you a longer lasting safety product than the previous generation of mechanical safety edges.
• Code-compliant: Meets the requirements of the ASME A17.1 and CAN/CSA B44 codes in order for building owners to possess the same codes ensuring their buildings to be both safe and insured.
• Low Maintenance Costs: The P40+SLEDGE minimizes impacts on mechanical works to the elevator doors and motors; thereby, extending their life span.

Common Application

• Contemporary users: Modern commercial offices: Fast and reliable protection for large buildings;
• Healthcare: Safe passage for stretchers, wheelchairs, and sensitive medical equipment;
• Boutique residential buildings: Low-profile discreet safety solution for the residential lifts;
• Public transportation hubs: Delivering dependable service in airports and train stations.
